kP4101 Programmable Noise Generator
This programmable noise generators covering frequencies from 1Mhz to 1GHz.
Applications include:
- BER Testing (Eb/No, C/N, SNR)
- Jamming
- Jitter tolerance testing
- GPS receiver testing
- EMI testing
- System and component test
kP4101 programmable noise generators offer a convenient, economical, rugged instrument ideal for all automated testing requiring noise. Manual control via an intuitive touch screen interface, remote control is via Ethernet. Frequency bands cover 1Mhz to 1GHz.
General Specifications
Output White Gaussian noise Power 115/240VAC, 50/60 Hz Standard connectors SMA female Ethernet Touch screen display 3U high enclosure (1U Optional) Operating Temperature: -10° to +65°C
Model | Frequency | Power | Flatness | Spectral Power | Noise Attenuation | Datasheet |
kP4101 | 1MHz to 1GHz | 0dBm | +/- 2.5dB | -90dBm/Hz | 127.9dB in 0.1dB steps | ![]() |
